| Brand Name: | RELIGHT |
| Model Number: | DOB Module |
| MOQ: | 100M |
| Price: | Contact us to get best price |
| Payment Terms: | T/T |
| Supply Ability: | 10000M/M |
Absolute maximum rating at 25℃
|
P/N
|
Size
|
Input
|
Power
|
PF
|
Flux
|
Efficiency
|
CCT
|
CRI
|
Dimming
|
|
mm
|
Vac
|
W
|
-
|
Lm
|
Lm/W
|
K
|
-
|
-
|
|
|
RL-HMD86A2802H018-827FF
|
Ø86
|
230
|
18
|
0.9
|
1980
|
110
|
2700
|
80
|
TRIAC
|
|
RL-HMD86A2802H018-830FF
|
Ø86
|
230
|
18
|
0.9
|
2070
|
115
|
3000
|
80
|
TRIAC
|
|
RL-HMD86A2802H018-840FF
|
Ø86
|
230
|
18
|
0.9
|
2160
|
120
|
4000
|
80
|
TRIAC
|
|
RL-HMD86A2802H018-850FF
|
Ø86
|
230
|
18
|
0.9
|
2160
|
120
|
5000
|
80
|
TRIAC
|
|
RL-HMD86A2802H018-865FF
|
Ø86
|
230
|
18
|
0.9
|
2160
|
120
|
6500
|
80
|
TRIAC
|
Optical-Electrical Characteristics at 25℃
| Input | 200-240Vac |
| Frequency | 50/60Hz |
| Rated power | Typical power(±10% tolerance) |
| PF | >0.90 |
| Protection | IP20 |
| Surge level | 2.5KV |
| Hi-pot | 1.5KVac |
| Storage temperature | -30-85℃ |
| Operation temperature | -30-80℃(Ts ofled components) |
| Beam Angle | 120 deg |
| Flicker index | <5% |
