| Brand Name: | RELIGHT |
| Model Number: | 0816 |
| MOQ: | 100M |
| Price: | Contact us to get best price |
| Payment Terms: | T/T |
| Supply Ability: | 10000M/M |
features:
Product Description
| P/N | LED Quantity | CCT(K) | CRI | LED | Lumens (lm/m) | Vf. | Current (mA/m) | Power (W/m) | Cut Length(MM) | Max Run |
| (SM) | (v.) | |||||||||
| RL-FV2410120283512-XXX-FWS0816 | 2835 | 2700 | 80/90 | 120 | 240 | 24V | 500mA | 12W | 50mm | 5m |
| 3000 | 240 | |||||||||
| 4000 | 250 | |||||||||
| RL-FV2410140283512-XXX-FWS0816 | 2835 | 2700 | 80/90 | 140 | 290 | 24V | 500mA | 12W | 50mm | 5m |
| 3000 | 290 | |||||||||
| 4000 | 300 | |||||||||
| RL-FV2410192283514-8CW-WS0816 | 2835 | 2700+6500K | 80/90 | 192 | 280 | 24 | 583mA | 14W | 62.5mm | 5m |
| RL-FV2410060505012-RGB-FWS0816 | 5050 | R::620-625 | / | 60 | 17 | 24 | 500mA | 12W | 100mm | 5m |
| G:515-520 | 42 | |||||||||
| B:465-470 | 9 | |||||||||
| RL-FV2410060505012-SPI-FWS0816 | 5050 | R::620-625 | / | 60 | 25 | 24 | 541mA | 13W | 100mm | 5m |
| G:515-520 | 63 | |||||||||
| B:465-470 | 15 | |||||||||
| RL-FV2410060505012-DMX-FWS0816 | 5050 | R::620-625 | / | 60 | 25 | 24 | 541mA | 13W | 100mm | 5m |
| G:515-520 | 63 | |||||||||
| B:465-470 | 15 |
Other Specifications
| Protection grade | IP67 |
| Working temperature(°C) | -25~+60 |
| Storage environment temperature (°C) | -25~+70 |
| Standard length | 5 |
| Maximum cascade length(m) | 5 |
| weight | / |
Remark
The test environment temperature is 25±2°C;
The above data are typical values, the actual parameters of the product may be different from the typical data; the data is subject to change without notice;
The above "/" means that this parameter is not required for the time being.
